Fine Pixel Direct View Active LED Display

Ultra-High Resolution for Exceptional Clarity

Direct view LED video wall technology is becoming an increasingly popular video wall solution due to its seamless image, scalability to any size or shape, and excellent optical characteristics that make video wall content look great from any angle. With advanced technology and design innovation, SEGi LED video wall solutions meet the needs of nearly any LED video wall customer.

Our product provides a seamless, high-resolution, high-contrast display solution for interior areas with short viewing distances. Its compact and lightweight design guarantees easy and quick installation. The indoor LED series delivers the excellent image and video quality in any indoor setting. Using the most advanced PWM (Pulse Width Modulation) image processing technology, the Indoor LED series ensures an excellent, flicker free viewing experience. These products are now widely used in high-end retail, transportation applications (flight and railway transit), command centres, conference halls along with broadcast studios where the quality of the display is extremely important.

Active LED Displays are known for its Vibrant colors, Seamless large Screens, and modular designs. The TrueColor Technology ensures exact color reproduction as in the original content resulting in the best Video and image output on the screen. The flexibility and modular design of LED Screens makes it a perfect solution for various applications like Broadcast studios, Control Room Displays, Indoor and Outdoor Advertising, Large Events and shows, Board Rooms and Meeting Room etc. SEGi LED has a team of experienced engineers with capabilities of chip level repairing. Our consultative approach helps our clients to get the right solution as per their application and budgets.

Specially designed Active LED displays are lightweight and agile. Making the process of installation and dismantling of cabinets easier and effortless. High tenacity and excellent heat dissipation are some unique features. It comes with a special interlock mechanism between cabinets which allows for a ±15 degree of angular installation. This enables us to have a curved screen setup as per site requirements. These displays are light weight and requires no supporting structure which helps in a quick and effortless process of installation and dismantling of LED Display resulting in time saving.

Technical Parameters- Indoor Led Video Wall Displays

Operating Environment

Indoor Series

Pixel Configuration

SMD 3 in 1

Parameter Series/

Model No.

ID Series

SP2X5

ID Series

SP3X0

ID Series

SP4X0

ID Series

SP4X8

ID Series

SP6X0

Pixel Pitch (mm)

2.5-2.9

3.0-3.9

4.0-4.7

4.8-5.9

6.0-6.9

Cabinet Size (mm)

As per Cabinet Standards

Cabinet Type

Mild Steel / Aluminium Diecast / Magnesium Alloy / Carbon Fiber / Polymer Alloy / higher

LED Type

SMD 1212 | SMD 1515 | SMD 1921 | SMD 2121 | SMD 2525 | SMD 2727

Pixel Density (pixels/sqm)

160000-112896111111-6574662500-4432043500-2822427777-21002

Driving IC

IC as per requirement

Brightness (nits or cd/m²)

800-1500

Contrast Ratio

10000:1

Grey Scale (Bit)

12-16

Service Access

Front / Rear

Pixel Calibration

Standard Color & Brightness Calibration

Drive Mode

Constant Current

Color Temperature

2000 K ̴ 10000 K Adjustable

HDR 10

Yes

Power Redundancy

Optional

Signal Redundancy

Optional

Angular / Curved Installation

Optional

Flexible Installation

Optional

Minimum View Distance(m)

≥2.5≥3.0≥4.0>=4.8≥6

Refresh Rate (Hz)

≥3840≥3840≥3840≥38408≥3840

Working Voltage

100-240 V AC 50/60 Hz

Viewing Angle

160° / 160°

Power Consumption (W/m²)

100-350

Ingress Protection

IP 30 | IP40 | IP50 | IP31 | IP41

Earth Leakage Current

<3mA

MTBF (hours)

>10,000

Life Span (hours)

>1,00,000

Operating Temperature

-30° C ̴ 60° C

Storage Temperature

-30° C ̴ 60° C

Humidity Range

5 % RH ̴ 95% RH

Preferred Applications:

Indoor Fixed Installation, Events Rental Industry, Auditorium, Conference Halls, Control Rooms, Data Centre, Command & Control Centre, New Rooms, Malls, Retail, Information Display, Airports, Railway Stations, Metro Stations, Petrol Stations, Stadiums, Smart Cities, Banks, Hotels, Clubs, etc.

Remark: Above data is subject to change & adjustment without prior notice due to continuous R&D by our team. The above specifications can be customized with technical enhancements to meet buyer/client requirement, necessary arrangements are made in the product to meet the required parameters. The offered product shall be as per requirement of buyer & hence precise details can be sought from our team. Offered product specifications are adjusted & revised in order to match the actual product performance & specifications.

Play any content you want

The benefit of a video wall is that it can capture signals from a variety of devices and play the video in high resolution. Devices such as computers, cable boxes, cameras, etc. can all be played on the wall and with much better clarity.

Better viewing experience with superior quality

The benefit of a video wall is that it can capture signals from a variety of devices and play the video in high resolution. Devices such as computers, cable boxes, cameras, etc. can all be played on the wall and with much better clarity.

Retail Outlets
Hospitality
Education
Transportation
Petrol Stations
DOOH / Digital Advertising
Banking
Construction
Public Places like Railway station
Healthcare
Manufacturing / Industrial
Sports
Benefits of Indoor LED Video Wall
SEGi LED, the leading manufacturer of Indoor LED Display.

Why choose SEGi LED:

  • At SEGi LED, we have over years of involvement in the field of LED shows, electronic signs and data show frameworks.
  • Works with the latest and advanced design and manufacturing process.
  • Focused on giving you the best client experience
  • Committed to plan, improvement, and production of superb, financially savvy signs and LED shows.

Thus, simply call our team of professionals who will help in providing you the best outdoor led video wall experience for your concern. Which will bring a lot of benefits for your concern such as:

LED Display System is an integrated solution that contains a huge number of resolutions. These are not the only places for an indoor LED wall to display. Any of the businesses can use these walls and the usage varies as per the business. Hotels, bars, restaurants are a high footfall place and an owner would like to improve the number of visitors and raise sales regardless. As it is eye-catching and mood-setting, a hotel or a restaurant is the best place to put up a digital signboard. You ought to set the mood correctly for the consumers in those locations so that your hotel or restaurant brand rises at a great rate. There are infinite possibilities for the LED video wall for clubs/pubs/restaurants/hotels when you can use it to attract your clients or promote your brand to drive traffic. For example, a multimedia monitor may be set up for many uses in a hotel lobby, such as hosting visitors, introducing classes to the grounds, directing and educating them about the hotel and other tourism areas, etc. Other platforms do not provide the kind of effect that an indoor LED video wall would have in such locations. It can be shown as a rare work of art that never ceases to draw publicity.

Improve your revenue base
Improves your business reputation
Improves your customer satisfaction rate
Helps in completing your orders on and well before the delivery dates
Bring sustainability to your business growth
Efficient engineering
High Grade Components
largest In-house service team in the industry with chip level repair capabilities
Zero Downtime
